Syllabus of Online and Offline Electrical Design Course
solar design training syllabus

Module-1 System planning

  • Basic design considerations
  • Planning guide for the supply and distribution system
  • Power system modernization and evaluation studies/program
  • Voltage considerations
  • Voltage control in electric power systems
  • Voltage selection
  • Voltage ratings for low-voltage utilization equipment
  • Voltage drop considerations in locating the low-voltage/ high-voltage
  • Calculation of voltage drops

Module-2 Cost estimating of industrial power system

  • Preparing the cost estimate
  • Classes of estimates
  • Equipment and material costs
  • installation costs
  • Other costs

Chapter- 3 LIGHTING DESIGN

  • Different entities of illuminating systems
  • Light sources: daylight, incandescent, electric discharge, fluorescent, arc lamp and Lasers
  • Luminaries, wiring, switching & control circuits
  • Laws of illumination; illumination from point, line and surface sources Photometry and spectrophotometry
  • Interior lighting – industrial, residential, office departmental stores, indoor stadium, theater and hospitals.
  • Exterior lighting- flood, street, aviation and transport lighting, lighting for displays and signaling- neon signs, LED-LCD displays beacons and lighting for surveillance
  • Utility services for large building/office complex & layout of different meters and protection units
  • Different type of loads and their individual protections
  • Selection of cable/wire sizes; potential sources of fire hazards and precautions.
  • Prepare layout of Different type lights
  • Refer Std:- IES(illumination Engineering Society )
  • IES (illumination Engineering Society)
  • IS 3646Code of Practice for Interior Illumination
  • IEC62504 General Lighting — LEDs and LED Modules —terms and definitions
  • National Lighting Code (Nlc)-2010
  • IS 6665 Code of Practice forIndustrial Lighting
  • IS 1944 Code of Practice for Lighting of public Thoroughfares
  • IEC 60598-2-3 Particular requirements – Luminaires for road and street lighting

Chapter- 4 Cable Sizing and Selection of single Phase and Three Phase

    • Load Details Calculation
    • Cable type and Construction features
    • Site Installation Conditions
    • Cable Selection Based on Current Rating of feeder
    • Base Current Ratings of feeder
    • Installed Current Ratings of Cable
    • Cable Selection and Coordination with Protective Devices
    • Feeders load detail
    • Motors load detail
    • Voltage Drop of cable
    • Cable Impedances
    • Maximum Permissible Voltage Drop by ANSI and IEC std.
    • Calculating Maximum Cable Length due to Voltage Drop
    • Short Circuit Temperature Rise calculation of cable
    • selection Minimum Cable Size Due to Short Circuit Temperature Rise
    • Initial and Final Conductor Temperatures withstand capability of cable
      Ref.Std.IEC
      • IEC 60364-5-52:election and erection of electrical equipment –Wiring systems
      • IEC 60364-5-54:Selection and erection of electrical equipment –Earthing arrangements, protective conductors and protective bonding conductors
      • IEC 60502-2: Power cables with extruded insulation and their accessories for rated voltages from 6kV up to 30kV
      • IS 7098 (Part 2)-1985:Specification for Cross-linked polyethylene insulated PVC sheathed cables–Specification (3.3kV to 33kV).
      • IS 1255:Code of practice for installation and maintenance of power cablesup to and including 33 kV rating

      Module-5 Internal Electrification design

      • Electrical Layout in residential building using Auto CAD
      • Selection of house wiring
      • Sizing and Selection of Conduit
      • Sizing and selection of Switch Socket
      • Calculation of load on circuit
      • Design of sub circuit (Lighting Circuit and Power Circuit)
      • Distribution of Power Circuit
      • Calculation of fan
      • Calculation of Earthing for residential buildings
      • Sizing and selection of low voltage switchgears (MCB,MCCB, RCB, RCBO MPCB)
        Refer Std. IS 4648,CPWD

      Module-6 PROTECTION OF BUILDINGS AND ALLIED STRUCTURES AGAINST LIGHTNING

      • Method of Lightening protection
      • Basic Consideration for Protection
      • Calculations for Evaluating the Need for Protection
      • Calculation of Protective Angles And Zone Of Protection For Various
        Forms of Air Termination
      • Selection of lightening protection device
      • Selection of ESE type Lightening Protection
        Rfer Std.
        IS 2309,NFC 72-102

Module-7 Earthing Design and Calculation of Power Plants .

  • Factors Influencing The Choice Of Earthed And Unearthed Systems
  • System Earthing &Equipment EarthingConnections To Earth
  • Resistance to Earth and Earth Electrode Current Density at The Surface of an Earth Electrode
  • Selection of an Earthing Conductor and Connection af an Electrode
  • Chemical Earthing Calculation
  • Voltage Gradient around Earth Electrodes
  • Connections to Earth Electrodes — Earthing And Protective Conductors
  • Earthing Arrangement for Protective Purposes
  • Earthing Arrangement for Functional Purposes
  • Earthing Arrangements For Combined Protective And Functional Purposes
  • Equipotential Bonding Conductors
  • Typical Schematic of Earthing And Protective Conductors
  • Earthing In Power Stations And Substations
  • Earthing Associated With Overhead Power Lines
  • Calculation of Earth Fault Currents
  • Measurement of Earth Resistivity
  • Measurement of Earth Electrode Resistance
  • Measurement of Earth Loop Impedance
  • Equipotential Bonding Conductors
Earhing Calculation For Switchyard And Power Plants
  • Step Voltage,Touch Voltage
  • Design Procedure
  • Calculation of Maximum Step And Mesh Voltages
  • Refinement of Preliminary Design
  • Application of Equations For EmAndesUse of Computer Analysis In Grid Design
  • Std. Ref. IS, IEC. IEEE, BS
    • IEEE Std 80-2000 Guide for Safetyin AC Substation Grounding.
    • BS 7430 Code of practice forEarthing
    • IS : 3043Code of Practice for Earthing

    Module-8 DESIGN AND ENGINEERING OF TRANSMISSION LINE

    • Transmission Planning
    • Indian Electricity Rules and State Regulations for transmission line
    • Choice of Route of transmission line
    • Selection of conductors for Overhead transmission
    • Spacing of Conductors in transmission lines
    • Calculation of SAG and Tension
    • Overhead transmission line Clearance
    • Selection of structure Pole, Lattice, Tower
    • Survey of transmission line upto 220KV
    • Sag Template and Tower Spotting
    • Classification of soil of Soil for 220KV transmission line
    • Tower Erection at Site Condition
    • Choice of Spans for 440kV transmission
    • Transmission line Earthing Calculation
    • Selection of Transmission line Insulator and fittings
    • Overhead transmission line lightning Calculation
    • Transmission line maintaince and erection solution

    Module-9 DESIGN AND ENGINEERING OF SWITCHYARD

    • Selection of project – Classification – Zone/Area wise
    • Electrical Clearance of substation
    • Insulation Coordinationcalculation of Equipment
    • Outdoor Substation Layout
    • Control Room Layout
    • Types of bus-bar schemes of Substation
    • Substation Main Equipment
    • sizing of Transformers
    • Reactive Compensation Equipment
    • Shunt Capacitors
    • Static VAR Systems
    • Selection and Sizing of Voltage Transformers (VT) for switchyards
    • Selection and Sizing of Current Transformers (CT)
    • HT/LT Circuit Breaker Selection and Sizing
    • Control& Relay Panels
    • Standard Protection Schemes for Substation and Transmission line
    • Substation Automation system design
    • Selection of PLC, Communication protocol
    • Benefits of Substation Automation system
    • Substation Automation with IEC 61850 Standard
    • selection and sizing of Disconnectors and earth switches (isolators)
    • selection and sizing of Lightning Protection
    • Selection of luminaries
    • Selection and sizing of Bus Support Insulators
    • Selection and sizing ofStrain Insulators
    • Power line carrier Equipment (PLCC)
    • Earthing of Switchyard
    • Cabling of Switchyard
    • Fire Protection Facilities in Substation
    • DC Auxiliary supply/ Battery bank Sizing and selection
    • Ref. Std
      • IEEE Std 80-2000 :Guide for Safetyin AC Substation Grounding.
      • IS 5613:Code of practice for design, installation and maintenance of overhead power lines,
      • IEC 60071-2:Insulation co-ordination – Part 2:
      • IEC: 62271-100:High-voltage switchgear and controlgear
      • IEC 826-1991: Technical report on loading and strength of overhead transmission lines.
      • IEC 60853:Sections on operating conditions – Reference operating conditions and selection of cable type
      • IEC 60949:Calculation of thermally permissible short-circuit currents, taking into account non-adiabatic heating effects
      • IS 3646: Code of Practice for Interior Illumination
      • Chapter 10 - Electrical Sofware

        • ETAP
        • DaiLux
        • Autocad
